Electric Heating Wood Chip Drying Equipment 380v 3 Phases 50Hz Customized

Electric Heating Wood Chip Drying Equipment 380v 3 Phases 50Hz Customized

    • Electric Heating Wood Chip Drying Equipment 380v 3 Phases 50Hz Customized
  • Electric Heating Wood Chip Drying Equipment 380v 3 Phases 50Hz Customized

    Product Details:

    Place of Origin: China
    Brand Name: LUY

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Negotiable
    Packaging Details: Nude packing, can be shipped by containers or bulk cargo
    Delivery Time: Shipped in 35 days after received payment
    Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
    Supply Ability: 5000 set per year
    Contact Now
    Detailed Product Description
    8. Treat Capacity: Can Be Customized Design Temperature: 60℃
    Using Temperature: 30-60℃(you Can Adjust It ) Electricity Voltage: 380v 3 Phases 50Hz(can Be Customized)
    Installation: Overseas Service Provided Control Ways: Intelligent Control
    High Light:

    wood chip drying equipment

    ,

    wood chip dryer machine

    High Frequency Wood Drying Machine Electric Heating Under Vacuum Condition



    Ⅰ Product description



    Wood Vacuum Drying Machine is a relatively small and fast timber drying equipment. It adopts HF electric field as heating source, uniformly radiate to timber, directly heat moisture, speed up moisture removing by vacuum water absorption function, which is extremely suitable for solid wood and all kinds of timber processing factory.



    Ⅱ Technical parameters



    Design temperature(℃) 60℃
    Using temperature(℃) 30-60℃(you can adjust it )
    Electricity voltage 380v 3 phases 50Hz(can be customized)
    Material Q345R carbon steel
    Open way Manual open door
    Control ways Intelligent control



    Ⅲ Main Model



    Model Effective treat capacity(cubic meter)
    DF1800*3500 3.5 cubic meters
    DF1800*4500 4.5 cubic meters
    DF1800*5500 5.5 cubic meters
    DF1800*8000 8 cubic meters
    DC1800*10000 10 cubic meters



    Note: If the above model is not available, please tell us your treat capacity you need. We can customize it for you.



    Ⅳ Our advantage



    Vacuum Drying -- 60°C starting to vaporize, which can reduce wood cracking and deformation while achieving low temperature drying


    Warp deformation Recovering --- Wood clamped by hydraulic system before drying, warping deformation to be recovered when soften , making outturn greatly improving and make easy palletizing


    Quick heating --- No need heat conduction, inside and outside of wood timber are heated at the same time


    Fast dehydration--- During the heating process, stepped temperature difference between inside and outside of wood can speed up the water movement from inside wood to outside wood


    High quality--- Avoid outside & inside cracking and color change, by taking control of heating speed, relative vacuum degree and condensing rate.


    Good adaptability---It can achieve both low temperature and high temperature drying, also can eliminate stress, solidify resin and apply to dry almost all kinds of wood


    Full-automatic & Easy operation --- Automatic feeding and discharging device, drying proceeding under unattended mode


    Cost saving --- Low dry shrinkage and material saving



    Electric Heating Wood Chip Drying Equipment 380v 3 Phases 50Hz Customized 0
