1m To 60m Timber Creosote Treatment Plant Passed Government Test With Filter System

1m To 60m Timber Creosote Treatment Plant Passed Government Test With Filter System

  • 1m To 60m Timber Creosote Treatment Plant Passed Government Test With Filter System
  • 1m To 60m Timber Creosote Treatment Plant Passed Government Test With Filter System
  • 1m To 60m Timber Creosote Treatment Plant Passed Government Test With Filter System
  • 1m To 60m Timber Creosote Treatment Plant Passed Government Test With Filter System
1m To 60m Timber Creosote Treatment Plant Passed Government Test With Filter System
Product Details:
Place of Origin: China
Brand Name: LUY
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Nude packing, can be shipped by containers or bulk cargo
Delivery Time: Shipped in 35 days after received payment
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 5000 set per year
Contact Now
Detailed Product Description
Origin: China Installation: Overseas Service Provided
Delivery Time: About 35 Days Length: From 1m To 60m (Can Be Customized)
Working Medium: Creosote Oil Treat Capacity: Can Be Customized
High Light:

cca treatment plant

,

wood pressure treatment plant

Can Be Customized Creosote Treatment Plant Passed Government Test With Filter System



Ⅰ Product description



This creosote treatment plant equipped with heating system, the heat source can be provided by a thermal oil furnace or a steam boiler. If the customer's company does not have a boiler, we can also provide it for you.



Creosote wood pole treatment plant is mainly used to treat creosote wooden pole, and is suitable for non-water soluble pharmaceuticals such as creosote oil.



Ⅱ Main Model



Type Effective Diameter(mm) Effective Length(mm) Total capacity(cubic meter) Effective treat capacity(cubic meter)
DC1500*12000 1500 12000 21.1 14.1
DC1500*8000 1500 8000 14.1 9.4
DC2000*14000 2000 14000 43.9 29.3
DC2200*16000 2200 16000 60.8 40.5
DC2500*26000 2500 26000 127.5 85.0
DC1800*8000 1800 8000 20.3 13.5
DC1800*10500 1800 10500 26.7 17.8
DC1800*12000 1800 12000 30.5 20.3



Note: The maximum diameter which we can customize is 4.5m, the length can be customized according to users' needs.If the above model is not available, please tell us the diameter and length of the equipment you need. We can customize it for you.



Ⅲ Technical parameters





Material: Q345R carbon steel(high pressure vessel special material



Safety ways: Double safety interlock ,tank with three safety interlock

Open door ways: Manual quickly open door

Design temperature(℃): 150℃

Design pressure(Mpa): 1.58Mpa

Working pressure:1.0-1.4mpa



Ⅳ Technology Process



1. Initial vacuum ,before add creosote ,begin initial vacuum,the purpose is to extract air cell ,reduce the resistance when the creosote entry into the wood/wood poles,in order to immerse better wood/wood poles The vacuum degree is 79.8-90kpa ,the time is up to product requirement.



2. Add creosote . In the vacuum state ,we add creosote ,and there is liquid level with storage tank ,after fill of the creosote oil .stop the valve.



3. heat stage ,open open button to heat creosote oil to dilute it.



4. Increase pressure : increase pressure into 1.0-1.4Mpa ,then keep pressure.



5. Discharge pressure and discharge creosote ,open the valve ,let the creosote oil come back to storage tank ,when it get liquid gauge level min limited , stop the valve.



6. Final vacuum ,open the vacuum system ,to extract the rest creosote oil ,reduce dropping liquid



7.  take out of wood/wood poles.



Ⅴ Advantages



1. The material is Q345R steel which has good physical properties.Material is we purchased from famous manufacturer, quality is absolutely guaranteed.



2. The galvanized sheets which will not rust in ten years welded and fixed around the equipment and built in insulation cotton to ensure make full use of heat energy. The thickness of the insulation cotton is 50mm. Reduce heat loss and save energy and reduce processing costs.



3. Steam boiler as a heat source, heat pipes distribution in the left, right and bottom of the equipment, to ensure uniform heating



4. Our equipment using automatic angle seat valve, it can automatically make the equipment to maintain the vacuum. So the vacuum degree is better than other equipments.



1m To 60m Timber Creosote Treatment Plant Passed Government Test With Filter System 0
