High Frequency Wood Drying Kiln / Wood Drying Chamber Large Capacity

High Frequency Wood Drying Kiln / Wood Drying Chamber Large Capacity

  • High Frequency Wood Drying Kiln / Wood Drying Chamber  Large Capacity
High Frequency Wood Drying Kiln / Wood Drying Chamber  Large Capacity
Product Details:
Place of Origin: China
Brand Name: LUY
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Nude packing, can be shipped by containers or bulk cargo
Delivery Time: Shipped in 35 days after received payment
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 5000 set per year
Contact Now
Detailed Product Description
Treat Capacity: Can Be Customized Design Temperature: 60℃
Diameter: 1.8m 9.Delivery Time: About 35 Days
Installation: Overseas Service Provided Working Principle: High Frequency Drying
High Light:

wood chip drying equipment


wood drying equipment

High Frequency Wood Drying Machine Environmental Protection Can Be Customized


Ⅰ Product description


Wood Vacuum Drying Machine is a relatively small and fast timber drying equipment. It adopts HF electric field as heating source, uniformly radiate to timber, directly heat moisture, speed up moisture removing by vacuum water absorption function, which is extremely suitable for solid wood and all kinds of timber processing factory.


Vacuum Drying -- 60°C starting to vaporize, which can reduce wood cracking and deformation while achieving low temperature drying
Warp deformation Recovering --- Wood clamped by hydraulic system before drying, warping deformation to be recovered when soften , making outturn greatly improving and make easy palletizing
Quick heating --- No need heat conduction, inside and outside of wood timber are heated at the same time
Fast dehydration--- During the heating process, stepped temperature difference between inside and outside of wood can speed up the water movement from inside wood to outside wood

Ⅱ Technical parameters


Design temperature(℃) 60℃
Using temperature(℃) 30-60℃(you can adjust it )
Electricity voltage 380v 3 phases 50Hz(can be customized)
Material Q345R carbon steel
Open way Manual open door
Control ways Intelligent control


Ⅲ Main Model


Model Effective treat capacity(cubic meter)
DF1800*3500 3.5 cubic meters
DF1800*4500 4.5 cubic meters
DF1800*5500 5.5 cubic meters
DF1800*8000 8 cubic meters
DC1800*10000 10 cubic meters


Note: If the above model is not available, please tell us your treat capacity you need. We can customize it for you.


Ⅳ Our advantage


1. Vacuum drying reduces the temperature of water evaporation inside the wood, and ensures that the wood is not cracked due to high temperature, improve the quality.

2. When the power is off, the electrodes are not heated and the working environment is greatly improved.

3. Fast and efficient (drying time of ordinary drying equipment is basically more than ten days to one month, high frequency drying only takes a few days, greatly shortening the production time)

4. Environmental protection and energy saving, eliminating the need for boilers or other heating sources.

5. It is more advantageous to heat thicker wood.


High Frequency Wood Drying Kiln / Wood Drying Chamber  Large Capacity 0
