Customized Autoclave  Carbon Steel or Stainless Steel









Home ProductsWood Treatment Plant

High Frequency Wood Treatment Equipment More Than 10 Years Experience

High Frequency Wood Treatment Equipment More Than 10 Years Experience

  • High Frequency Wood Treatment Equipment More Than 10 Years Experience
  • High Frequency Wood Treatment Equipment More Than 10 Years Experience
  • High Frequency Wood Treatment Equipment More Than 10 Years Experience
  • High Frequency Wood Treatment Equipment More Than 10 Years Experience
High Frequency Wood Treatment Equipment More Than 10 Years Experience
Product Details:
Place of Origin: China
Brand Name: LUY
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Nude packing, can be shipped by containers or bulk cargo
Delivery Time: Shipped in 35 days after received payment
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 5000 set per year
Contact Now
Detailed Product Description
Effective Length: From 1m To 60m (Can Be Customized) Effective Diameter: Can Be Customized
Vacuum Degree: -0.098Mpa Materia: Q345R Carbon Steel
Working Medium: Water-soluble Agent, Like CCA ACQ Tanalith Material Thickness: 12mm 14mm(can Be Customized)
High Light:

timber treatment plant

,

wood impregnation plant

More Than 10 Years Experience Wood Treatment Plant Sold To Tanzania



Ⅰ Product description



This wood Treatment Plant have been sold to the Myanmar, Russia, Thailand, South Korea, Philippines, Tanzania, Kenya, Uganda, Sweden and so on. Wood treatment plant mainly used for deep processing of wood, vacuum pressure treatment method, so the wood to achieve anti-corrosion, pest control, and other purposes.



Has a wide use range, safety and reliability, and can meet the deep processing requirements of users for various types of wood.



This wood treatment plant applied to various water-soluble chemicals such as CCA, ACQ, boric acid, Tanalith E and etc.







Ⅱ Main Model



Model Effective Diameter(mm) Effective Length(mm) Total capacity(cubic meter) Effective treat capacity(cubic meter)
DN1500*4000 1500 4000 7.0 4.7
DN1500*6000 1500 6000 10.6 7.0
DN1800*8000 1800 8000 20.3 13.5
DN2000*14000 2000 14000 43.9 29.3
DN2200*16000 2200 16000 60.8 40.5
DN2500*12000 2500 12000 58.8 39.2
DN2500*14000 2500 14000 68.6 45.7
DN1800*10500 1800 10500 26.7 17.8
DN1200*4000 1200 4000 4.5 3.0
DN1200*6000 1200 6000 6.7 4.5



Note: The diameter and length can be customized according to users' needs. If the above model is not available, please tell us the diameter and length you need. We can customize it for you.





Ⅲ Technical parameters



Design pressure:1.58MPA

Working medium: various water-soluble like CCA ACQ

Working pressure:1.0-1.4MPA

Material:Q345R carbon steel

Voltage:380v 3 phase 50hz(can be customized according to users’ needs)

Vacuum operation:-0.098MPA







Ⅳ Technology Process



Extract Vacuum---holding vacuum and adding medicament---open the pressurizing pump after reaching the liquid level ---maintain the required pressure to infuse the medicament into the wood cells for a period of time—pressure unloading—discharge Reagents --- Vacuum again --- Restoring atmospheric pressure --- Open the tank door and remove the wood --- Complete



Ⅴ Our advantages



1. Our equipment automatically controls pressure and vacuum,our equipment once reach the pressure or fixed vacuum , the pressure pump or vacuum pump will stop by itself , once lower than the fixed point, the pumps will start working by automatic control system.
Each day saving much production cost for the users .



2.-- The material of this machine is Q345R steel, is the special steel plate for pressure vessel, we purchase from famous Jinan steel factory.



3. -- We have special sewage outlets to prevent the residual chemicals flowing out, will not pollute the factory floor.



4. -- Many of our valves are automatic control stainless steel valves, which are several times the price of ordinary valves.



5. -- Regardless of whether it is a vacuum pump, air compressor or pipeline, our configuration is relatively high, and the equipment is highly working efficient, which also saves costs for users.



High Frequency Wood Treatment Equipment More Than 10 Years Experience 0
